Floating seal, also known as torque seal, seal set, double cone seal, mechanical face seal, lifetime seal
2. Metal seal shortage: 230/260
3. Life: 5000 hours / 8000 hours
4. Warranty: 18 months for each shipment, maintenance service
The seal set consists of a metal ring and a rubber gasket.. metal ring:
| Surface treatment / Roughness | ≤Ra0.2μm |
| face End | ≤Ra0.015μm |
| pressure | MP 0.3 MPa |
| Mesh Line speed | 2 m / sec |
| modeling Line speed | 3 m / sec |
|
temperature
|
-100~200 degrees Celsius |
Rubber gasket:
| Difficult edge | 60 degrees to 65 degrees |
| at the lowest limit tensile strength | Llnf |
| at the lowest limit Promotion break | 300% |
| flexible Variety | ±5 degrees |
| Permanent deformation | ≤12% |
The benefits of our products:
1. Experience high quality and competitive price
2. Long service life
3. Easy to install
4. High yield
5. Good performance
installation method:
1. Product Equipment Installation: The pressure on the O-RingDirectory will apply. As shown, the special equipment is mounted on the seat hole between the metaphor ring and the rubber ring, and the rubber ring is evenly pressed into the hole.
2. Other mounting methods: The tapered surface of the auxiliary O-ring floating oil seal and the top surface of the O-ring (as shown) are fixed. The floating oil seal ring is also suitable for pressure and useful O-ring brackets. Seal the O-ring to ensure other wrong moving columns.
There are many specifications, I only list a small part. If you don't find what you want, please contact me. Thank you!
Standard type
|
4176379 |
38 mm |
51 mm |
20k4mm |
|
1791292 |
63k5mm |
82k5mm |
3lk8mm |
|
170-27-00010 |
L30mm |
L5lmm |
32 mm |
|
9W 6668 |
L63k3mm |
L9lk2mm |
38 mm |
|
9 W 6672 |
L82k3mm |
2l0k3mm |
38 mm |
|
9 W 3732 |
264k9mm |
292k8mm |
38 mm |
|
4066695 |
298 mm |
328 mm |
42 mm |
L type
|
Product number |
OD |
diameter |
height |
|
Ul7386 |
62.1 |
47.1 |
10 |
|
Ul6l87 |
72 |
54 |
10 |
|
Ul6l86 |
87 |
66.9 |
11.6 |
|
655973c9l |
93 |
73.5 |
10 |
XY type
|
Product number |
OD |
diameter |
height |
|
7t4080 |
70.5 |
53.7 |
31.5 |
|
7t0l58 |
82.2 |
66.5 |
31 |
|
7t0l59 |
93 |
76 |
32.5 |
|
7t0l57 |
99 |
82 |
32.5 |
Iron plate type
|
Product number |
OD |
diameter |
height |
|
TZ300A-1010 |
180 |
164 |
9.7 |
|
TZ310B-1027 |
185 |
158.7 |
12.3 |
|
TZ550A-1010 |
210 |
186 |
11.4 |
|
TZ850A-1010 |
230 |
201 |
13.3 |
|
TZ150A-1010 |
260 |
216 |
13.3 |
|
TZ150F-1027 |
284 |
247 |
13.3 |
|
TZ200B-1010 |
290 |
248 |
13.3 |
About packaging:
Our boxes come in three styles. We also have coaches and trays. We put the group in the box, and then we put a lot of boxes in the carton.
About our factory:
Our products are widely used in crawler excavators, excavators, heavy vehicles and machinery. Customers throughout the country and Southeast Asia, Europe and the United States, always satisfied. Using RVTOn Floating Seal Ringwill makes you more powerful and successful.
Welcome to the following contact information Messi Quick answer:
Massey Cao
Massey Cao - Sales Director
Email - floatingseal03@rvton.com
Skype - rvton.seals
Whatsapp- 0086 13886465358
Facebook - Cao Meixi
QQ - 2972 72701
Straight line - 0086 15717237241
Actiteepi://wwvksealgroupsuppliarkcom
Huangshi Ruidun Machinery Co., Ltd.
1004, Block 5, Yijing Plaza, Huangshi City, Hubei Province, China
Tele 0086 15717237241 0086 15717233790
Fax - 0086 714 6277689
Highly customized tea processing machine to meet your special needs, strictly product quality control is our requirement .
1.material:Forge/cast iron metal seal + NBR/silicone/Viton rubber ring
2.size: inner diameter 30mm - 1000mm
3.Type: New Holland 520067809 Heavy duty seals for Tractor Cultivator Finishing Mowers
4.package:Inner packing in shrink wrapped plastic bags and boxes,
outer packing in cartons and wooden pallets.And can also meet your packing demands.
5.sample lead time:Stock available,order lead time:1- 2 weeks
6.Output:50000pcs per month
7.Shipping port: Shanghai,Ningbo,Xiamen,Shenzhen,any port as per request
1.material:Forge/cast iron metal seal + NBR/silicone/Viton rubber ring
2.size: inner diameter 30mm - 1000mm
3.Type: 9W7216 Seal Group for Caterpillar 2M2858 Spare Replacement Parts
4.package:Inner packing in shrink wrapped plastic bags and boxes,
outer packing in cartons and wooden pallets.And can also meet your packing demands.
5.sample lead time:Stock available,order lead time:1- 2 weeks
6.Output:50000pcs per month
7.Shipping port: Shanghai,Ningbo,Xiamen,Shenzhen,any port as per request
1.material:Forge/cast iron metal seal + NBR/silicone/Viton rubber ring
2.size: inner diameter 30mm - 1000mm
3.Type: Komatsu PC40-7 140-30-00141 FLOATING SEAL
4.package:Inner packing in shrink wrapped plastic bags and boxes,
outer packing in cartons and wooden pallets.And can also meet your packing demands.
5.sample lead time:Stock available,order lead time:1- 2 weeks
6.Output:50000pcs per month
7.Shipping port: Shanghai,Ningbo,Xiamen,Shenzhen,any port as per request
1.material:Forge/cast iron metal seal + NBR/silicone/Viton rubber ring
2.size: inner diameter 30mm - 1000mm
3.Type: Undercarriage 4060222 Hitachi Floating Seal supplier
4.package:Inner packing in shrink wrapped plastic bags and boxes,
outer packing in cartons and wooden pallets.And can also meet your packing demands.
5.sample lead time:Stock available,order lead time:1- 2 weeks
6.Output:50000pcs per month
7.Shipping port: Shanghai,Ningbo,Xiamen,Shenzhen,any port as per request
1.material:Forge/cast iron metal seal + NBR/silicone/Viton rubber ring
2.size: inner diameter 30mm - 1000mm
3.Type: 76.90 H-24 A3 cast iron 15Cr3mo NB60 Mechanical face Seal supplier
4.package:Inner packing in shrink wrapped plastic bags and boxes,
outer packing in cartons and wooden pallets.And can also meet your packing demands.
5.sample lead time:Stock available,order lead time:1- 2 weeks
6.Output:50000pcs per month
7.Shipping port: Shanghai,Ningbo,Xiamen,Shenzhen,any port as per request
1.material:Forge/cast iron metal seal + NBR/silicone/Viton rubber ring
2.size: inner diameter 30mm - 1000mm
3.Type: PV15V00026S117 Genuine CNH OEM Part Floating seals for Kobelco SK35SR-6
4.package:Inner packing in shrink wrapped plastic bags and boxes,
outer packing in cartons and wooden pallets.And can also meet your packing demands.
5.sample lead time:Stock available,order lead time:1- 2 weeks
6.Output:50000pcs per month
7.Shipping port: Shanghai,Ningbo,Xiamen,Shenzhen,any port as per request
1.material:Forge/cast iron metal seal + NBR/silicone/Viton rubber ring
2.size: inner diameter 30mm - 1000mm
3.Type: PADO Seal 238-261-32 EP Goetze 76.90H-40 replacement
4.package:Inner packing in shrink wrapped plastic bags and boxes,
outer packing in cartons and wooden pallets.And can also meet your packing demands.
5.sample lead time:Stock available,order lead time:1- 2 weeks
6.Output:50000pcs per month
7.Shipping port: Shanghai,Ningbo,Xiamen,Shenzhen,any port as per request
1.material:Forge/cast iron metal seal + NBR/silicone/Viton rubber ring
2.size: inner diameter 30mm - 1000mm
3.Type: GZ 5830 GNL metal face seals in China
4.package:Inner packing in shrink wrapped plastic bags and boxes,
outer packing in cartons and wooden pallets.And can also meet your packing demands.
5.sample lead time:Stock available,order lead time:1- 2 weeks
6.Output:50000pcs per month
7.Shipping port: Shanghai,Ningbo,Xiamen,Shenzhen,any port as per request
