Floating Seal is a Seal Used in Rotating Body Exposed to Silt and Sand.The Floating Seal Is a Kind of A Combination Seal Composed of High Hardness C ...
Floating Seal is a Seal Used in Rotating Body Exposed to Silt and Sand.The Floating Seal Is a Kind of A Combination Seal Composed of High Hardness C ...
Floating Seal is a Seal Used in Rotating Body Exposed to Silt and Sand.The Floating Seal Is a Kind of A Combination Seal Composed of High Hardness C ...
Floating Seal is a Seal Used in Rotating Body Exposed to Silt and Sand.The Floating Seal Is a Kind of A Combination Seal Composed of High Hardness C ...
Floating Seal is a Seal Used in Rotating Body Exposed to Silt and Sand.The Floating Seal Is a Kind of A Combination Seal Composed of High Hardness C ...
Floating Seal is a Seal Used in Rotating Body Exposed to Silt and Sand.The Floating Seal Is a Kind of A Combination Seal Composed of High Hardness C ...
Metal rings:
| Surface finish / Coarseness | Μ Ra 0.2 μm |
| Face End | ≤ Ra 0.015 μm |
| Pressure | A 0.3MPa |
| Forged line speed | 2 m / From |
| Casting line speed | 3 m / From |
|
Temperature
|
-100 ~ 200 ° C |
Rubber rings:
| Set aside the difficulty | 60 ° ~ 65 ° |
| The minimum Tensile strength | 11MPa |
| The minimum elongation at break | 300% |
| Flexible Change | ± 5 ° |
| Permanent deformation | ≤ 12% |
Advantages of our product:
1. Survival of high quality and competitive prices
2. Have long service life
3. Easy to install
4. High yield
5. Good performance
Method of installation:
1.Usingspecialized equipment installation: The pressure will apply to the O-ringdirectly. As shown, the special tool is placed between the metal hole ring and the rubber ring, towards the seat hole, the rubber ring is pressed evenly into the hole.
Also there are a lot of specifications which I list just a small part. Enjoy me for asking if you haven't found what you want. Thanks!
Standard type
|
4176379 |
38mm |
51 mm |
20.4mm |
|
1791292 |
63.5mm |
82.5mm |
31.8mm |
|
170-27-00010 |
130mm |
151mm |
32mm |
|
9W 6668 |
163.3mm |
191.2mm |
38mm |
|
9W 6672 |
182.3mm |
210.3mm |
38mm |
|
9 W 3732 |
264.9mm |
292.8mm |
38mm |
|
4066695 |
298mm |
328mm |
42 mm |
L type
|
Product number |
OD |
Diameter |
The height |
|
U17386 |
62.1 |
47.1 |
10 |
|
U16187 |
72 |
54 |
10 |
|
U16186 |
87 |
66.9 |
11.6 |
|
655973C91 |
93 |
73.5 |
10 |
XY Type
|
Product number |
OD |
Diameter |
The height |
|
7T4080 |
70.5 |
53.7 |
31.5 |
|
7T0158 |
82.2 |
66.5 |
31 |
|
7T0159 |
93 |
76 |
32.5 |
|
7T0157 |
99 |
82 |
32.5 |
Iron plate type
|
Product number |
OD |
Diameter |
The height |
|
TZ300A-1010 |
180 |
164 |
9.7 |
|
TZ310B-1027 |
185 |
158.7 |
12.3 |
|
TZ550A-1010 |
210 |
186 |
11.4 |
|
TZ850A-1010 |
230 |
201 |
13.3 |
|
TZ150A-1010 |
260 |
216 |
13.3 |
|
TZ150F-1027 |
284 |
247 |
13.3 |
|
TZ200B-1010 |
290 |
248 |
13.3 |
About Packing:
There are three styles of our box. And we also have coaches and trays. We put the putative group in the box, then put several boxes in the boxes.
About our factory:
Our company's products are widely used on crawler dozen, excavators, heavy vehicles and machinery. All over the country and Southeast Asia, Europe and America, and customers always feel satisfied. Using the RVTON floating seal ringvale makes you even more powerful and successful.
Highly customized tea processing machine to meet your special needs, strictly product quality control is our requirement .
1,Part #:
2,New Aftermarket parts
3,Material: Steel 100CR6 + NBR60
4,Metal Hardness: 58-62 HRC
5,Rubber Hardness: 60-65°
6,Lifetime: 3000-5000 hours
7,Warranty: 18 months
8,Stock offered
9,Packing: Shrink films + Inner box + standard export carton + wood pallet + wood box
1.Part#:95BR02534
2.New aftermarket parts
3.Material: Steel 100CR6 + NBR60
4.Metal Hardness: 58-62 HRC
5.Rubber hardness: 60-65 °
6.Lifetime: 3000-5000 hours
7.Warranty: 18 months
8.Stock offered
9.Packing: Shrink films + inner box + standard export carton + wood pallet + wooden box
1.Part#:GNL 5860
2.New Aftermarket parts
3.Material: Steel 100CR6 + NBR60
4.Metal Hardness: 58-62 HRC
5.Rubber Hardness: 60-65°
6.Lifetime: 3000-5000 hours
7.Warranty: 18 months
8.Stock offered
9.Packing: Shrink films + Inner box + standard export carton + wood pallet + wood box
1.Part#:YN53D00008S023
2.New Aftermarket parts
3.Material:Steel 100CR6 + NBR60
4.Metal Hardness:58-62 HRC
5.Rubber Hardness:60-65°
6.Lifetime:3000-5000 hours
7.Warranty:18 months
8.Stock offered
9.Packing:Shrink films + Inner box + standard export carton + wood pallet + wood box
1.Part#:20Y-27-00110
2.New Aftermarket parts
3.Material:Steel 100CR6 + NBR60
4.Metal Hardness:58-62 HRC
5.Rubber Hardness:60-65°
6.Lifetime:3000-5000 hours
7.Warranty:18 months
8.Stock offered
9.Packing:Shrink films + Inner box + standard export carton + wood pallet + wood box
1.Part#:VOE14528713
2.New Aftermarket parts
3.Material:Steel 100CR6 + NBR60
4.Metal Hardness:58-62 HRC
5.Rubber Hardness:60-65°
6.Lifetime:3000-5000 hours
7.Warranty:18 months
8.Stock offered
9.Packing:Shrink films + Inner box + standard export carton + wood pallet + wood box
1.Part#:2445Z1110
2.New Aftermarket parts
3.Material:Steel 100CR6 + NBR60
4.Metal Hardness:58-62 HRC
5.Rubber Hardness:60-65°
6.Lifetime:3000-5000 hours
7.Warranty:18 months
8.Stock offered
9.Packing:Shrink films + Inner box + standard export carton + wood pallet + wood box
1.New Aftermarket parts
2.Material:Steel 100CR6 + NBR60
3.Metal Hardness:58-62 HRC
4.Rubber Hardness:60-65°
5.Lifetime:3000-5000 hours
6.Warranty:18 months
7.Stock offered
8.Packing:Shrink films + Inner box + standard export carton + wood pallet + wood box
