New price Caterpillar 3144128 SEAL GROUP-DUO-CONE on Sales

  • 1. Lifetime: 5000Hours/8000hours
  • 2. Hardness: 58-62HRC/62-68HRC
  • 3  seal material: 100cr6, Gcr15, E52100, 534A99, SUJ2
  • 4. inner diameter: 38mm - 1000 m
  • 5. material of O-Ring: NBR/Viton/silicone/HNBR
  • 6  process seal: forging and casting
  • 7  ring color: black/blue/red/custom
  • 8. Warranty:18 months after shipment
  • 9  ring rubber hardness: 60-65 °
  • Product Details




Product description
  •      Seal of Rvton is also called floating seal, the seal group, seal the cone Duo, face mechanical seal, seal of lifelong
  •      the zipseal outer diameter is 35 mm-1, 000 mm.
  •      Hardness HRC58-62, the precision of the face of work in 0. 015um.
  •      Plain up to 0.1um-0.2um, the duration is more than 4, 000 hrs.

    Rvton seal group set are consist of metal or rubber rings or ring



    QQ20150128191839

  •  -Metal rings



    Surface finish / Roughness of the ≤ Ra0.2μm
    Face Finish ≤ Ra0.015μm
    Pressure ≤ 0.3 MPa
    Forged /Casting  line speed 2m / s and  3m / s
    Hardness 58-62 HRC
    Temperature

     -100 ~ 200 ° C



     -Rubber ring or



    Shore hardness 60 ° ~ 65 °
    Minimum tensile strength  11MPa
    Minimum elongation at break  300%
    Flexible change  ± 5 °
    permanent deformation ≤ 12%
OEM Service
Impressions of OEM steel could be free



Model

OEM codes

KOMATSU

195-30-00302 154-30-00831, 141-30-00616, 150-27-00017, 207-27-0001, 130-27-00140, 27-130-0001, X-27 - 14 00101, 150-27-0002, 170-27-00020, 423-33-00020, 17 M-27-00101, 287-33-00010, 425-33-00110, 568-33-00016, 209-27-00160, 141-27-00010, 130-27-B0100, 180-27-00021 175-27-00121

140-30-00040 130-27-00010, 150-30-00035, 170-27-00010...

Kobelco

R45P0018D, R45P0018D6, 45P0018D18, R45P00018D9, R45P0018D25,

R45P0018D12, R45P0018D27, R45P0018D13, R45P0018D14, R45P0018D15, R45P0018D16, R45P0018D18, R45P0018D29, R45P0018D21, YN53D00008S023, R45P0018D22, R45P0018D28...

Caterpillar

1 M 8746, 9W7225, 9W7220, 8E5609, 8E 5610, 9W 7232, 2 M 2858, 7223 9W, 9W 6649, 1M 8747, 9W 6647, 6648 9W, 6V2733, 9W7233, 1M 8746, 3395-2 P, 1 P 7249, 5 P 7147, 3 0433 P, 5 P 9120, 6645 9W, 9W 6666, 5 9, 5 M 1176 1078, 5314 K, 9W 6674, 9-5317, 9W7201...

Hitachi

4283635, 4176379, 4177260, 4082631, 4642180, 4110363, S-110,

4110362, 4153732, 4508193, S-209, 4114753, 4514259, ES-250, 4179741, 4066695, 4138544, 4350347, 4082698, S-56, 64 IS...



20140409150127

Packaging and shipping

Packing: neutral, yellow, white packing box and welcome your logo on packing






Shipping: FOB Shanghai, Ningbo, Shenzhen, xiamen according to request.



Application:
-Farm, construction, earthmoving, coal mining machinery

-Excavator, Bulldozer, tractors, cranes, forklift, heavy truck, backhoe

-Of journey Undercarraige, hydraulic motor, engine, gearbox shaft, wheel hub, tunneling

-For OEM Komatsu, Caterpillar, Shantui, Sany, Kubota, Kobelco, JCB, Volvo, Hitachi,
   John Deere, New Holland, Commins, Terex, Fiat Allis, BOB-CAT... etc..



Fairs

Rvton welcomed many customers during Bauma 2014, it is a valuable experience for us.




Welcome to Rvton cabin N2.469 in Bauma 2016 Shanghai China, make appointments with Macy's free.


Company information

Rvitong of Huangshi Machinery Comapany Limited

1. a factory founded in 2004.

2. two production line:

    r. one is for piece forgeable 100Cr6, hardness HRC58-62, working time is 5000 HRS;

    b. two is for iron-cast 15Cr1Mo/15Cr3Mo, is hardness of HRC62-68, working time is from 8000 hrs.

3 inside diameter 35-1,000 mm.

4. four different types: type standard, type XY, type L and iron plate type.

HTB1RtNDHpXXXXazapXXq6xXFXXXq

Frequently asked questions

1. What is a real manufacturer for floating labels?

     Rvton is a real manufacturer to float only seals. We also design seals floating, draw floating seals, Assembly and manufacture of seals. Us accept design client, drawing and samples.


2. as a company of interior, how to arrange the shipment?

    This could be our advantage, as we are located in the Centre of China, is We take same times to send goods to Wuhan, ShanghaiNingbo, Port of Xiamen or Shenzhen. We can deliver most of the sea ports shipments and DHL UPS TNT Fedex EMS freely to door express service.



3. how long does it take usually to finish an order?

    3 - 4 weeks for a common order around 1000 and continue regular reservations for sample order or trial orders, which can provide immediate delivery.





4. Tell us more about the manufacturing process?

    Leading manufactuer process listed in the table below, don't hesitate to ask more.



More questions? Any request now?

WELCOMe following contact Macy's for a fast response, fast service online




Macy Cao

Email - floatingseal03 @ rvton.com

Skype: rvton.seals

WhatsApp: 0086-13886465358

TM: cn1500379557

Tel: 0086 15717237241

Web site: www.sealgroupsupplier.com
