| 1 set | It consists of two metal sealing rings and two rubber seals |
| Part# | 420-30-00020 |
| Weight | 3.84kgs |
| Availability: 5 sets | |
| Material | 100CR6 steel + NBR60 |
| Lifetime | 3000-5000 hours |
| FOB | Wuhan, Shanghai, Qingdao, Ningbo, Shenzhen, Xiamen |
| Package |
Shrink films + Inner box + standard export carton + wood pallet + wood box |
| Guarantee | 18 months |
Machines
Part#
Komatsu
110-30-00085 110-30-00045 141-30-00610 140-30-00040 140-30-00141 170-30-00110 170-30-00210
175-30-00070 175-30-00700 20Y-30-00040 130-27-00020 150-27-00025 150-27-00026 150-27-00027
204-30-00041 20Y-30-00100 10Y-30-00100 150-30-00035 154-30-00035 154-30-00830 154-30-00832
154-30-00833 170-27-00010 198-30-00072 21T-30-00110 198-30-00072 423-33-00020 423-33-00021
205-30-00052 14X-27-00100 566-33-00010 205-30-00050 195-27-00022 175-27-00120 175-30-00900
205-30-00200 20Y-30-00430 22U-30-00060 22B-30-00030 20Y-30-13210 204-30-00100 198-30-00073
175-27-00102 205-27-00040 21N-30-00040 207-27-00310 421-33-00050 17M-27-00101 208-27-00140
195-27-00100 568-33-00016 562-33-00200 TZES 100-154S TZES 100-154B TZ-ES100-250-A
Caterpillar
9G5311 9W6666 1M8747 9W6647 5M1176 6T8433 9G5315 9W6671 9W6680 9W7220 8E5609 9W7225
6P3595 9G5345 9W6690 9W6691 9W7216 2M2858 9W7223 9W6691 1P7249 5P7146 9W7243 7M0481
5P0204 7T0159 9W6651 9W7233 7T0157 108-6997 5P0373 9W7213 9P9663 8E2042 9W6694 9W3732
1141497 9W7201 9W7202 9W6620 9W6619 9W3956 169-6442 6Y0855 9W7204 6Y0856 9G5349 3144128
205-9025 9W7204 6Y0856 9G5349 1796862 1796863 145-6034 9W6644 9W6822 3T6602 365-4920
2627244 3176441 9W7206 1796864 1C9748 1456035 3144130 1791292
Hitachi
4176379 4110358 4128201 4508192 4128201 4508192 4060222 4110359 4512571 4060225 4047279
4104605 4110360 4153468 4163731 4068433 4153711 4163711 4110362 4153732 4508193 4056360
4111361 4507221 4642180 4110366 4110367 4513173 4092483 4082631 4110368 4110369 4114753
4634693 4514259 4179741 4066695 4317584 4138544 4082698 ZAX200-5G XKAH-00916 XKAQ-00219
XKAH-01012 4245703 / 4200413 / 4350347 / 4344155 4082698
Others
58845-01500 R45P0018D2 R45P0018D3 TD00348/17 R45P0018D4 5691020160 MT4000-7918
R45P0018D6 JB5680 619-89900440 71418383 05/903811 1.180-00512 CR3069 XZ993774 MT40211881
R45P0018D21 R45P0018D25 TD0352/04 0964294 5691020340 5691020530
R45P0018D12 2445Z1110 R45P0018D27 TD00611/02 R45P0018D13 UK 5500 R45P0018D14
204-50805000 R45P0018D14 R45P0018D15 760S126FS TLDOA1460 R45P0018D16 R45P0018D18
R45P0018D8 R45P0018D29 RG-30 OK5110 H-25 JB5820 619-95032001 R45P0018D20 760S247F JS2650S YN53D00008S023 LQ15V00020S067 R45P0018D22 760S297FS YN15V00037S029
11.3209 24100U1743S24 R45P0018D28 58845- 20500 U14568 45P0018D18 45P0018D18 R45P00018D9
988430 R45P0018D9 20306 U16184 2445Z1109
| METAL | Steel Gcr15/ 100Cr6 | Cast 15Cr3Mo |
| Surface smoothness/roughness: | ≤Ra0.2μm | 6.3-12.5μm |
| Work face smoothness | ≤Ra0.15μm | ≤Ra0.1μm |
| Pressure loading | ≤0.15MPa | ≤0.3 MPa |
| Forging line speed | 2m/s | 3m/s |
| Temperature range | —100~200°C | -40~160°C |
| Hardness (HRC) | 58-62 | 60-68 |
| Lifetime (Hours) | 3000 | 5000 |
| Material | NBR60 | SILICONE | FKM |
| Hardness | 60°~ 65° | 60°~ 65° | 72°~ 78° |
| Minimum tensile strength | 11MPa | 10.6Mpa | 11MPa |
| Minimum elongation at break | 300% | 400% | 260% |
| Permanent deformation | 12% | 8% | 25% |
| Temperature range | -40℃- +120℃ | -49℃- +230℃ | -30℃- +250℃ |
| Specific Gravity(g/cm3） | 1.25 | 1.2 | 1.8 |
-Why Rvton deliver so fast?
-As we stock lots of raw materials,packing boxes and completed products.
-You're the factory?
Yes, we are a 13 years factory in Hubei Province, China
- How do you control the quality?
Each seal is 100% inspected in every process before exported
- How long to make the shipment?
In three days with stocks, 15-30 days according to the order qty.
- Can i buy one to test?
Yes, we offer a trial order and sample order for your Quality Evaluation.
Welcome to contact us and visit us!
For more information, please contact me! Good offer will be sent to you.
Fay Xu
Sales Representative
E: floatingseal04@rvton.com
T: 8615327878823
Skype: fay.xu3
Wechat: Rvtonseal04
Whatsapp: 86 15327878823
Highly customized tea processing machine to meet your special needs, strictly product quality control is our requirement .
1.material:Forge/cast iron metal seal + NBR/silicone/Viton rubber ring
2.size: inner diameter 30mm - 1000mm
3.Type: Komatsu HM300-3 Center Axle, Final Drive Brake Seal Assembly
4.package:Inner packing in shrink wrapped plastic bags and boxes, outer packing in cartons and wooden pallets.
And can also meet your packing demands.
5.sample lead time:Stock available,order lead time:1- 2 weeks
6.Output:50000pcs per month
7.Shipping port: Shanghai,Ningbo,Xiamen,Shenzhen,any port as per request
1.material:Forge/cast iron metal seal + NBR/silicone/Viton rubber ring
2.size: inner diameter 30mm - 1000mm
3.Type: Big size ring floating seal 76.90 HEL-127 A2 for American Gears
4.package:Inner packing in shrink wrapped plastic bags and boxes, outer packing in cartons and wooden pallets.
And can also meet your packing demands.
5.sample lead time:Stock available,order lead time:1- 2 weeks
6.Output:50000pcs per month
7.Shipping port: Shanghai,Ningbo,Xiamen,Shenzhen,any port as per request
1.material:Forge/cast iron metal seal + NBR/silicone/Viton rubber ring
2.size: inner diameter 30mm - 1000mm
3.Type: Kobelco SK60 Mark 3 Undercarriage Parts 2441U532S24 Floating Seal
4.package:Inner packing in shrink wrapped plastic bags and boxes, outer packing in cartons and wooden pallets.
And can also meet your packing demands.
5.sample lead time:Stock available,order lead time:1- 2 weeks
6.Output:50000pcs per month
7.Shipping port: Shanghai,Ningbo,Xiamen,Shenzhen,any port as per request
1.material:Forge/cast iron metal seal + NBR/silicone/Viton rubber ring
2.size: inner diameter 30mm - 1000mm
3.Type: New Aftermarket and Non Oem Parts IN2285 Seal Groups
4.package:Inner packing in shrink wrapped plastic bags and boxes, outer packing in cartons and wooden pallets.
And can also meet your packing demands.
5.sample lead time:Stock available,order lead time:1- 2 weeks
6.Output:50000pcs per month
7.Shipping port: Shanghai,Ningbo,Xiamen,Shenzhen,any port as per request
1.material:Forge/cast iron metal seal + NBR/silicone/Viton rubber ring
2.size: inner diameter 30mm - 1000mm
3.Type: CNH (FIAT-ALLIS) - 5145028 - SEAL
4.package:Inner packing in shrink wrapped plastic bags and boxes, outer packing in cartons and wooden pallets.
And can also meet your packing demands.
5.sample lead time:Stock available,order lead time:1- 2 weeks
6.Output:50000pcs per month
7.Shipping port: Shanghai,Ningbo,Xiamen,Shenzhen,any port as per request
1.material:Forge/cast iron metal seal + NBR/silicone/Viton rubber ring
2.size: inner diameter 30mm - 1000mm
3.Type: ISO9001 long Lifetime face seals TLDOA1480 for construction machinery
4.package:Inner packing in shrink wrapped plastic bags and boxes, outer packing in cartons and wooden pallets.
And can also meet your packing demands.
5.sample lead time:Stock available,order lead time:1- 2 weeks
6.Output:50000pcs per month
7.Shipping port: Shanghai,Ningbo,Xiamen,Shenzhen,any port as per request
1. Material: Forging metal rubber ring/seal Iron mould + NBR/silicone/Viton
2. Size: Inner diameter 30mm-1000mm
3. Type: XKAH-00916 excavator wheel duo cone seal Hyundai R210LC-7
4. Package: Inner packing in shrink wrapped plastic bags and cartons, outer packing in cartons and wooden pallets.
And it can also meet your packaging demands.
Link Time 5. Sample: Available stock, order link deadline: 1-2 weeks
6. Output: 50000pcs per month
Port Seven. Shipping: Shanghai, Ningbo, Xiamen, Shenzhen, any door as per request
1. Material: Forging metal rubber ring/seal Iron mould + NBR/silicone/Viton
2. Size: Inner diameter 30mm-1000mm
3. Type: Komatsu pc1750 Seal Group for TRACK EXCAVATOR
4. Package: Inner packing in shrink wrapped plastic bags and cartons, outer packing in cartons and wooden pallets.
And it can also meet your packaging demands.
Link Time 5. Sample: Available stock, order link deadline: 1-2 weeks
6. Output: 50000pcs per month
Port Seven. Shipping: Shanghai, Ningbo, Xiamen, Shenzhen, any door as per request
